3.1.9.1. Export 3D formats
3.1.9.1.3.  Export options" tab page -> Insert position, options, layer settings
Prev  Next
3.1.9.1.3.  Export options" tab page -> Insert position, options, layer settings

You can specify the insertion position [Insertion position] on the Export options tab page.

You will find the following settings in the Options section:

  • Insertion position: X and Y

  • Options:

    • Then insert into the active CAD application [Insert into active CAD application afterwards]:

    • Do not generate attributes [No Attributes]: ...prevents certain attributes (e.g. texts from PARTproject) from being transferred to the CAD system during export.

  • Attribute layer

    • Name: Free input of the layer name

    • Line type

    • Line color

    • Line weight

    • Visible - Make attributes visible in [Attributes visible in drawing area] the drawing area: yes/no

    In addition to the option of specifying certain lines and colors directly, you can also make the color and line setting dependent on the layer setting in the CAD system. To do this, select the "by layer " setting.

  • Attributes: See above for setting options

  • Layer 3D objects [Geometry layer]: See above for setting options

  • 3D objects [Geometry]: See above for setting options
