7.8.12.  Attribute algorithms

7.8.12.1. Set up feature algorithm - simple example
7.8.12.2. Syntax - Buttons for creating the formula
7.8.12.3. Specification of the error position in feature algorithms
7.8.12.4. Algorithms in tabular form
7.8.12.5. Error avoidance
7.8.12.6. Add comments
7.8.12.7. Mathematical functions (feature algorithm )
7.8.12.8. Translation functions

[Note]Note

You can find an example of feature algorithms in the training catalog ($CADENAS/training/training.cip) at \v11_news\value_ranges\value_ranges_with_condition\din_1771.prj.

So-called characteristic algorithms are used to express dependencies between variables . In the following example figure, you can see that the variable NENN is represented by the variables H, B and L .

NENN = '$H.x$B.x$L.'
