If in PARTdataManager for example variants are inserted via Add dataset to link database (variant) into the table, a correct sorting is not always guaranteed.

As of PARTsolutions V9.05 you can determine in an own dialog box, which schema has to be used for the sorting concerning the opened project. A manual editing of the PRJTABLE is not necessary anymore.

Procedure:

Click on the icon Set the sorting order for currently opened project.

-> The Change sorting order dialog box opens.

Under New sorting order insert the variables determining the sorting comma separated.

Confirm with Change sorting order. -> The new sorting is immediately performed and displayed.

Configuration:

In the configuration file under $CADENAS_SETUP/erpcustom.cfg, in the LOAD section a key with the value $CADENAS_SETUP/scripts/erp/erp_sorttable.vbb has to be activated.

Optionally a message can appear to point out that the sorting of variants possibly is illogical and that you have the opportunity to explicitly determine the sorting for the opened project. If desired, then in the configuration file under $CADENAS_SETUP/erpcustom.cfg, in the section ADDTODB_VARS activate the key with the value $CADENAS_SETUP/scripts/erp/erp_sorttable.vbb.

If this key is activated, then after setting a variant, the Change sorting order? dialog box appears. Not before the sorting has been explicitly determined, the dialog box will appear.
